From $300
Product Overview
The NBPG Parking Garage Fixture from NebuLite Technology Inc. represents the pinnacle of contemporary commercial lighting innovation. This state-of-the-art LED solution is meticulously engineered to excel in low-level illumination environments, offering a perfect blend of functionality, efficiency, and aesthetic appeal. With its streamlined, low-profile design and advanced technological features, this LED parking garage lighting is poised to revolutionize lighting in parking structures, service station canopies, commercial awnings, and a myriad of other applications demanding reliable, high-performance illumination.
At the heart of the NBPG’s versatility lies its field-adjustable wattage and color temperature capabilities. This groundbreaking feature empowers facility managers and lighting professionals to fine-tune their lighting systems with unprecedented precision. The fixture offers four selectable wattage options – 30W, 50W, 75W, and 100W – allowing for on-site optimization of light output and energy consumption to meet the specific requirements of diverse areas within a single installation. Complementing this flexibility, the adjustable color temperature settings of 3000K, 4000K, and 5000K enable users to craft the perfect ambiance, enhance visual comfort, and support the circadian rhythms of occupants. This adaptability not only simplifies inventory management but also future-proofs lighting investments by allowing easy adjustments to meet changing needs or regulations without the need for fixture replacement.
The NBPG Parking Garage Fixture goes beyond mere illumination; it’s a comprehensive lighting ecosystem designed to maximize energy efficiency, minimize maintenance, and enhance the overall user experience in commercial spaces. With its combination of cutting-edge LED technology, intelligent controls, and robust construction, this fixture sets a new benchmark for what commercial lighting can achieve in the modern built environment.
Key Features
– Low-profile square design with anti-glare PC lens
– Ultra-wide 160-degree beam angle for reduced light pollution
– Field-adjustable wattage: 30W / 50W / 75W / 100W options
– Selectable color temperature: 3000K, 4000K, 5000K
– High efficacy of 130 lm/W
– Bi-level occupancy sensor (ANT-9) with remote programming capability
– IP65-rated die-cast aluminum housing for optimal heat dissipation
– 0-10V dimming and Bluetooth Mesh Control options
– Hinged design for easy internal access
– Multiple mounting options: surface, ceiling, or pendant
Certifications and Compliance
– UL Listed
– DLC Premium Listed
– CE Certified
– RoHS Compliant
– California Title 24 Compliant
Technical Specifications
– Input Voltage: 100-277V AC
– Input Frequency: 50/60 Hz
– CRI: ≥80
– Power Factor: ≥0.9
– Rated Life: 50,000 hours (L70)
– Operating Temperature: -40°F to 125°F (-40°C to 52°C)
– LED Type: SMD 3030
– Beam Angle: 160 degrees
– Dimming: 0-10V
– IP Rating: IP65
Applications
– Parking garages and structures
– Gas station canopies
– Business plaza awnings
– Walkways and corridors
– Industrial facilities
– Storage areas
Customization Options
– Wattage selection: 30W, 50W, 75W, 100W
– Color temperature options: 3000K, 4000K, 5000K
– Mounting types: Ceiling Mount (CM) or Pendant Mount (PM) with 3/4″ pipe
– Optional ANT-9 Microwave Bi-Level Sensor
– RC-100 Remote Control for sensor programming
– Custom finish colors available (contact sales team for options)
Warranty
NebuLite Technology Inc. offers a 5-year limited warranty on the NBPG Parking Garage Fixture.
Ordering Information
To place an order, use the following format:
PGC-[Wattage]-[CCT]-[Voltage]-[Options]
Example: PGC-75W-50-ANT-9
– PGC: Series designation
– Wattage: 30W, 50W, 75W, or 100W
– CCT: 30 (3000K), 40 (4000K), or 50 (5000K)
– Voltage: Leave blank for standard 100-277V
– Options: ANT-9 (Microwave Sensor), RC-100 (Remote Control)
Additional Features
– 12V AUX output
– Knockouts on all 4 sides and back for flexible conduit connections
– Anti-aging electrostatic spray treatment on housing surface
– 6030-aluminum heat sink with anti-static powder coat paint
– Optional ANT-9 sensor features adjustable detection range, hold time, and daylight threshold
The NBPG Parking Garage Fixture offers an unparalleled combination of energy efficiency, adaptability, and robust construction. Its field-adjustable features and advanced sensor options make it an ideal choice for facility managers and property owners looking to optimize their lighting systems while reducing energy costs. With its long lifespan and versatile design, this fixture represents a smart, future-proof investment in commercial lighting technology.
